Rubber Membrane Keyboard Graphic Overlays For Human Machine interface

تصویر بزرگ : Rubber Membrane Keyboard Graphic Overlays For Human Machine interface

جزئیات محصول:

Place of Origin:	Dongguan China
نام تجاری:	TianTai
گواهی:	ISO9001:2008, SGS,Rohs
Model Number:	TT-MS-037

پرداخت:

Minimum Order Quantity:	50 pieces
قیمت:	USD 0.2~12
Packaging Details:	Inner packing:1pc/PP bag,PE bag,gift box Outer packing:exporter carton, or As per customer request
Delivery Time:	Around 14-18 business days after payment
Payment Terms:	T/T, Paypal or Western union
Supply Ability:	500000 Piece/Pieces per Month

مخاطب

توضیحات محصول جزئیات

برجسته:

membrane switch overlay,graphic overlay printing

graphic overlay printing

Rubber Membrane Switch Panel Graphic Overlays For Human Machine interface

Description:

Graphic overlay:

perfect exterior
Autotype PC or PET overlay
Finish: glossy or matt.
Rear Adhesive: 3M467 or 3M468
Matching color:Pantone and RALcolor matching system.
SMD welding or by hand welding as per request
metal dome or polydome, assemble with silicone keypad is also available.
Withstand millions of cycles
Standard Tolerances:+/- 0.10inch(+/-0.25mm)

	Polyester	Polycarbonate
Mechanical Resistance	Very high	Poor
Chemical Resistance	High	Poor
Thermal Resistance	Acceptable	Good
Abrasion Resistance	High	Acceptable
UV Resistance	Available	Not Available
Fatigue resistance	Superior (to 1,000,000 cycles)	poor
Dielectric Property	High	Good
flexure	great	poor
lifespan	Very good	Good (100,000 key cycles)
Range of surface finishes	Average	High
Transparency	Average to High	High
Thickness	.008” and thinner	.005” to .300” (and thicker)
Flammability	Not Available	Available
texture	limited	From fine mattes to course velvets

Applications:

Our membrane switches are widely used in :

Human Machine interface
Automatic Control Equipment
Telecommunications apparatus
Telephone systems
Household appliances
Security systems
Industrial controller
Access control systems.....

Specifications:

wire lead resistance:	＜1Ω/CM	Life time:	>1 Million times
rated current:	25-100mA,0～30V DC	Operation Temperature:	-40℃～70℃
Rated Voltage:	＜50V, DC	Operation Humidity:	at 40℃,＜98%RH
Insulation resistance:	＜100MΩ,250V DC	Dome springback time:	＜5 msec
Switch travel:	Flat Type 0.05-0.3mm	Base Material voltage withstand:	1500 V DC
Switch travel:	tactile type:0.3-1.5mm	Tail flexiblility:	any angle within 180 degree

1 material : PET /PC
2 adhesive: 3M467 & 3M468 or as per request
3 High life time :>1million times
4 Pass:ISO9001:2008 RoHS.SGS
5 High quality

Competitive Advantage:

1. Strong capability in R&D.

2. Professional staff in Production, management, and engineering, experienced in the industry for over 17 years.

3. Professional Sales team can provide quick service.

4 Low cost and top quality

5. Long lifespan,Our membrane switch is more than 100million times.

6. In-house 100% functionally tested before delivery.
7. Customized specification is available .
8. ISO9001:2008 certified company with three factories, Can provide one station resolution for client.
