جزئیات محصول:
پرداخت:
|
| برجسته: | PET protection film,transparent protective film,transparent protective film |
||
|---|---|---|---|
| Material: |
PET
|
Usage: |
Printing
|
Hardness: |
Soft
|
| Transparency: |
Transparent
|
Place of Origin: |
GuangDong(China)
|
Brand Name: |
YinSha
|
| Model Number: |
HC-Series
|
Base Film Thickness: |
100um-250um
|
Width: |
500mm-1000mm
|
| length: |
200m
|
core size: |
3"
|
1. Good hardness, 3H or above, anti scratch property is well.
2. Good printing adhesion force
3. IMD IML suitable
4. High clarity, less crystal points
5. Both sides with protective film, Blue or other color PE protective film in printing side and the hard coated side is transparrent PET protective film
| Item | Unit | Value | Test methods | ||||||
| Tensile strength | Mpa | MD 135 TD 156 | ASTM D 882 | ||||||
| Elongation at break | % | MD 141 TD 116 | ASTM D 882 | ||||||
| Heat shrinkage rate | % | MD 1.0 TD 0.1 | ASTM D 1204 150°C 30min | ||||||
| Transmittance | % | 95.0 | ASTM D 1746 | ||||||
| Haze | % | 1.0 | ASTM D 1746 | ||||||
| Surface hardness | _ | 3H | JIN-K-5400 | ||||||
| Peel strength | _ | 100/100 | 3M tape | ||||||
• Membrane switch,
• Instrument panel,
• Nameplate,
• Household appliances panel,
• Remote control.
